6 signs that it's time to replace your press brake

6 signs that it's time to replace your press brake

Jul 30, 2025

In sheet metal manufacturing, bending machines are a very critical link. However, many factories still have old bending machines that have been used for more than ten years. They seem to be "usable", but they have already become the "invisible killer" of production line efficiency, quality consistency and even customer satisfaction.

The following are 6 clear signals summarized from an engineering perspective, which show that your bending machine has dragged down your production capacity, profits, and even order opportunities —— it is time to consider upgrading and replacing the machine.






1. Bending accuracy is difficult to guarantee and rework is frequent



Common manifestations:

For the same batch of products, the angle deviation is ±2~3°, and the end "corner drop" is serious;

Workers repeatedly adjust the angle, resulting in high test piece costs and low yield rates;

The cumulative dimensional error after multiple bending steps is large, which affects assembly or welding.

The reason behind:

The structure of the old torsion shaft bending machine is worn and deformed;

The synchronization error is uncontrollable and there is a lack of closed-loop feedback from the grating scale;

Lack of real-time compensation mechanism.

Impact: Unstable precision → Customer returns → High quality control pressure → Lost orders

Recommendation: Upgrade to an electro-hydraulic servo bending machine (dual Y-axis independent control + closed-loop compensation), which can achieve angle control within ±0.5° and ±0.2mm repeatability.






2. Changing molds and adjusting machines is troublesome, changing orders is slow, and workers are annoyed



Common manifestations:

Changing the mold/plate thickness/angle all depends on manual adjustment, which takes 5 to 10 minutes of trial and error;

The CNC system cannot automatically adjust the gap, pressing, angle compensation, etc.;

Changing one process slows down the entire production line.

The reason behind:

Older press brakes lack automatic gap/angle/compensation systems;

The CNC system is too old (such as E21/E200) and only supports basic control;

There is no mold identification system and no prompts when changing molds.

Impact: Slow order change → High reliance on manual labor → Overall efficiency declines → Unsuitable for multi-batch flexible orders

Recommendation: Choose a new CNC bending machine with automatic die change (ATC), die recognition, and automatic loading of process programs (such as DA66T, ESA S660 system).






3. Hydraulic system frequently has problems, and maintenance becomes the norm



Common manifestations:

Oil cylinder leaks, seal fails, and system temperature rises;

The solenoid valve sometimes works and sometimes doesn't, and the action is "stuck" or "empty";

Hydraulic oil needs to be changed twice a year, and maintenance costs are rising year by year.

The reason behind:

The hydraulic system is aging, and the internal seals and valve groups are worn;

Low control accuracy, large movement impact, and increased wear;

The cooling system fails or the oil pump efficiency decreases.

Impact: Frequent downtime → High maintenance costs → Delayed delivery → Poor after-sales reputation

Recommendation: Upgrade to an electro-hydraulic servo system, using a proportional servo pump + intelligent temperature control + low-noise oil pump to extend system life, reduce energy consumption and maintenance pressure.






4. High energy consumption, high noise, poor operating environment



Common manifestations:

The main motor is running continuously, and is "wasting energy" even if it is not bending;

Noise is greater than 85 decibels and vibration is strong, affecting the health of operators;

The oil temperature rises quickly and overheating alarms frequently sound in summer.

The reason behind:

The traditional hydraulic bending machine is a quantitative pump + continuous pressure supply system;

There is no energy-saving mechanism and the motor runs at full speed throughout the entire process;

The old machine lacks energy-saving/quiet design.

Impact: Increased electricity costs → employee turnover → Failure to pass ISO environmental certification

Recommendation: Use an electro-hydraulic servo system + a low-noise hydraulic station to save 30-60% energy and significantly improve the workshop environment.






5. The equipment cannot be connected to the automation system and cannot keep up with the trend of intelligent manufacturing



Common manifestations:

Cannot connect to robotic arms/automatic stacking equipment;

The CNC system cannot communicate with the MES/ERP system;

Unable to collect data, track quality, or upload and download programs.

The reason behind:

The CNC system is closed or outdated and has no communication interface;

The control architecture does not support linkage with external devices;

No industrial bus or network connection capability.

Impact: Factory automation deployment is hindered → Falling behind peers → Wasted upgrade investment

Recommendation: Choose an open CNC system that supports OPC, Modbus, and Ethernet communications (such as Delem, ESA, Cybelec, etc.) to achieve intelligent factory connection.






6. Customer requirements have changed, and the old equipment is no longer able to meet the needs



Common manifestations:

New customer specified "stainless steel within ±1° error", which could not be achieved;

Overseas customers have stricter acceptance procedures, requiring video simulation and angle testing;

The customer needed to quickly deliver multiple model orders, and the old machine was difficult to handle.

The reason behind:

The market demands upgrades, but the equipment is not updated synchronously;

Unable to quickly respond to small-batch, high-variety orders;

Lack of digital management and control makes it impossible to meet customer quality tracking requirements.

Impact: Loss of old customers → Loss of large orders → Forced profit reduction → Loss of competitiveness

Suggestion: timely replacement of bending machines to keep up with the market rhythm will not only improve quality, but also enhance brand image and bargaining power.






Summary: Replacing bending machine ≠ spending money, it is "stop loss", not "whether it can be used", but "whether it can still help you make money"



When many companies are hesitating about whether to replace equipment, they often only look at whether the bending machine can still be used, but ignore a core fact: the real money spent is not on buying a new machine, but on rework, errors, delays, and customer loss caused by the "old machine".

If you find that the problems mentioned above are common in your factory, you may consider replacing it with a stable and intelligent bending machine provided by ZYCO to get your production line running again!
